Content:
*Supports 2 CHANNEL TBT Gen3, Gen4 full duplex high speed transmission..
*Supports 1 CHANNEL USB3.2 Gen1 or Gen2 or 2 CHANNEL Gen2 full duplex high speed transmission.
*Supports USB4 Gen2 or Gen3 full duplex high speed transmission.
*Supports 1-CH USB2.0 half duplex transmission.
*Support DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode.
*Dual-protocol support for USB4 mode
*Plug flip-able use
*Compliant with USB PD specification Revision3.0,Max PD capacity up to 5A

General Parameter:
*100% electrical testing, no short circuit, open circuit, dislocation and other bad phenomena.
*Insulatiuon resistance: 2MΩ MIN,DC300V
*Conductor resistance:3Ω MAX
*Withstand voltage: AC 250V, testing time: 0.01S 2mA MAX
