Content
◆ Supports TBT Gen3, Gen4 or Gen5 full duplex high speed transmission.
◆ Supports USB4 Gen2/Gen3/Gen4 full duplex high speed transmission.
◆ Supports 1-CH USB3.2 Gen1 or Gen2 or supports 2- CH USB3.2 Gen2 full duplex high speed transmission.
◆ Supports 1-CH USB2.0 half duplex transmission.
◆ Support DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode.
◆ Dual-protocol support for TBT mode (PCI Express and DisplayPort) and can be used for daisy-chaining devices.
◆ Triple -protocol support for USB4 mode (USB, PCI Express and DisplayPort*) and can be used for USB4 daisy-chaining devices.
◆ Plug flip-able use.
◆ Thin cable design, OD=5.1mm
◆ Compliant with USB Power Delivery Specification Rev3.1 Maximum power delivery capacity up to 5A.

General Specification
◆ Length: 0.5-meter / 0.8-meter / 1.0-meter
◆ Connector: LOTES Type-C connector or compatible
◆ Color: Black

Electrical Specification
◆ Transmission data rate:
- Thunderbolt: Thunderbolt Gen2/Gen3/Gen4/Gen5 full duplex operation.
- DP: DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode (MFDP).
- USB: 1-CH USB3.2 Gen1 or Gen2 full duplex operation.
2-CH USB3.2 Gen2 full duplex operation.
USB4 Gen2/Gen3/Gen4 full duplex operation.
1-CH USB2.0 half duplex operation.
◆ Operating Voltages: VBUS: 5V ~ 48V (typ.), VCONN: 5.5V (max) ~ 3.0V (min.)
◆ Power consumption: under 37.5mW.
◆ Current delivery capacity: 5A (max.)
◆ Compliant with USB Power Delivery Specification Rev3.1

Storage and Operation temperature
◆ Storage Temperature: Intel Thunderbolt Standard -20~85°C ambient.
◆ Operation Temperature: Intel Thunderbolt Standard 0~50°C ambient.
