Content
◆ Supports 2-CH Thunderbolt Gen2 or Thunderbolt Gen3 full duplex high speed
◆ Supports 1-CH USB3.2 Gen1 or Gen2 or supports 2- CH USB3.2 Gen2 full duplex high speed transmission.
◆ Supports USB4 Gen2/Gen3 full duplex high speed transmission.
◆ Supports 1-CH USB2.0 half duplex
◆ Supports DP1.4, 4-lane DisplayPort video signal transmission, DP alternate
◆ Dual -protocol support for Thunderbolt mode (PCI Express and DisplayPort*) and can be used for Thunderbolt daisy-chaining
◆ Triple -protocol support for USB4 mode (USB, PCI Express and DisplayPort*) and can be used for USB4 daisy-chaining
◆ Plug flip-able
◆ Thin cable design, OD=4.9mm (typ.)
◆ Compliant with USB Power Delivery Specification Rev3.0. Maximum power delivery capacity up to 5A

General Specification
◆ Length: 1.5 meter / 2.0 meter
◆ Connector: LOTES Type-C connector or compatible
◆ Color: Black, White

Electrical Specification
◆ Transmission data rate:
－Thunderbolt: 2-channel Thunderbolt Gen2 or Thunderbolt Gen3 full duplex operation.
－DP: DP1.4, 4-lane DisplayPort video signal transmission, DP alternate mode (MFDP).
－USB:
﹎(a) 1-CH USB3.2 Gen1 or Gen2 full duplex operation.
﹎(b) 2-CH USB3.2Gen2 full duplex operation.
﹎(c) USB4 Gen2/Gne3 full duplex operation.
﹎(d) 1-CH USB2.0 half duplex operation.
－Operating Voltages: VBUS: 5V – 20V (typ.), VCONN: 5V (typ.)
－Power consumption: 0.7W (typical)
－Current delivery capacity: 5A (max.)
－Compliant with USB Power Delivery Specification Rev3.0

Storage and Operation temperature
－Storage Temperature: Intel Thunderbolt Standard -20~85°C ambient
－Operation Temperature: Intel Thunderbolt Standard 0~40°C ambient
