Key features*
• Two M.2 NVMe SSD Sockets — Add up to 16TB of storage inside (SSDs sold separately); achieve data transfer speeds up to 3000 MB/s (SSDs configured as RAID 0 set).
• Connects to Your Peripherals with One Cable — Plug in peripherals to the dock with their cables, and then connect your computer to the dock with the included Thunderbolt cable for instant access.
• Front Panel Thunderbolt Port for Peripherals — Connects one Thunderbolt peripheral directly and supports daisy-chaining of up to five Thunderbolt devices. Also supports USB 4 and USB 3 peripherals.
• Powerful 10Gbps USB Ports — Four USB 3.2 Gen 2 ports provide up to 7.5W of power each for bus-powered peripherals, and for charging of devices.
• Quiet, Effective Cooling — Temperature-controlled, variable-speed fan automatically and quietly cools the dock and any installed SSDs
• macOS Boot Support — Supports booting from a single (non-RAIDed) SSD
• Apple Pro Display XDR Supported
• Several Display Types Supported — Connect a Thunderbolt or USB-C display directly. Supports an HDMI or DisplayPort display with a • Thunderbolt-compatible adapter (sold separately).
• Free Lifetime Customer Technical Support

—Mass SSD storage meets desktop dock convenience—
Dual NVMe slots support internal high performance storage expansion*. Transfer and access data in seconds, and effortlessly store large files and media libraries. Convenient, fast peripheral ports provide connectivity and charging for your Thunderbolt™ and USB devices. Compatible with all Thunderbolt 4 computers, all M1/M2 series Macs, all Thunderbolt 3 Mac and Windows computers, and M1/M2 iPad Pro.

—SSD Storage – Add up to 16TB of SSD Storage Inside—
The Echo Dual NVMe Thunderbolt Dock features two M.2 NVMe PCIe SSD slots, enabling you to easily install high performance M.2 NVMe SSDs (sold separately) inside. Because installed SSDs interface with the dock’s Thunderbolt controller, they utilize its bandwidth to deliver the performance of a portable Thunderbolt SSD, but are tucked away neatly within the dock.

—Speed – Fast Single SSD Data Transfers. Great RAID 0 Performance—
Single SSDs installed in the Echo Dual NVMe Thunderbolt Dock can each achieve sustained data transfers of up to 1500 MB/s. Configured as a RAID 0 set for even greater performance, data transfers up to 3000 MB/s are possible. Start with one SSD, and add any size SSD later without needing to format the first one.

—Connect Thunderbolt Peripherals – Convenient Front Panel Thunderbolt Peripheral Port—
The Echo Dual NVMe Thunderbolt Dock includes two 40Gbps Thunderbolt ports; one for connection to your computer, the other to daisy chain up to five additional Thunderbolt peripheral devices plus a display. The Thunderbolt peripheral port also offers 10Gbps USB 3.2 Gen 2 support, meaning you can connect another USB device using the proper cable or adapter. The dock’s Thunderbolt peripheral port provides up to 15W, supporting even the most demanding bus-powered Thunderbolt devices.

—Peripheral Power – Powerful 10Gbps USB ports—
The Echo Dual NVMe Thunderbolt Dock features four versatile USB 3.2 Gen 2 (10Gbps) ports (two Type-C plus two Type A) that support super-fast USB NVMe SSDs at full speed. Each port delivers up to 7.5W to ensure connected bus-powered devices operate without fail, and may be used to charge your iPhone®, iPad®, or other device that charges via USB.

* See Sonnet website for details.
