Sonnet Echo 11 Thunderbolt 4 Dock

  • Category: Dock
Sonnet Technologies, Inc.
Operating System:
MacOS
Operating System:
Windows
Self or Bus Powered:
Self Powered
Number of Thunderbolt Ports:
4
Thunderbolt Version:
Thunderbolt 4

Key Features*
• Four Thunderbolt 4 Ports (One Computer/90W Charging Port for Host Computer and Three Thunderbolt 4 Peripheral Ports)
• Three USB 3.2 Gen 2 (10Gbps) Type A Ports
• USB 2.0 Type A Charging Port (Provides Up to 7.5W of Power to Charge Bus-powered Devices)
• RJ45 Gigabit Ethernet Port
• 3.5 mm Combination Audio Headphone/Microphone Jack
• UHS-II SD Card Slot
• Display Support for 1080p, 1440p, 4K, 5K, 6K, and 8K Displays @ Up to 240Hz (See Displays Compatibility PDF)
• Connect Another Display via Thunderbolt – Connect a Thunderbolt or USB-C Display Directly. Supports an HDMI or DisplayPort Display with a • Thunderbolt Compatible Adapter (Sold Separately).
• Charge Your Laptop – Provides Up to 90W
• Includes 0.7-meter Thunderbolt 4 Cable
• Free Lifetime Customer Technical Support

—Universal Thunderbolt 4 Docking Station with Four Thunderbolt 4 Ports and 8K Display Support—
All the connections you expect from a Thunderbolt™ dock plus the Thunderbolt hub you've always wanted. With this extraordinary dock, a single cable connects your laptop to your digital world. Sonnet's Echo™ 11 Thunderbolt 4 Dock – the universal docking station for today and tomorrow. Compatible with Apple® M series Macs; Thunderbolt™ 3 Intel® Macs; Thunderbolt 3/4 and USB4 Windows computers; Thunderbolt 4 and USB4 Chromebook; and M series iPad Pro.

—Thunderbolt Multiplied – Turn One Thunderbolt Port into Three—
The Echo 11 Dock features four Thunderbolt 4 ports; one for connection to your computer, plus three to connect Thunderbolt peripheral devices directly and daisy chain up to a total of 5 additional devices. The Thunderbolt ports also support USB4 and USB 3 peripherals. For connected peripherals using bus power, the Dock’s Thunderbolt peripheral ports provide 15W per port, supporting even the most demanding bus-powered Thunderbolt and USB peripherals.

—Thunderbolt Certified for Mac, Windows, Chromebook, and iPad Pro—
Echo 11 Thunderbolt 4 Dock is certified for use with Apple M series Macs; Thunderbolt 3 Intel Macs; Thunderbolt 4 and USB4 Windows computers; Thunderbolt 3 Windows computers with an Intel 8th Gen (2018) or newer CPU; Thunderbolt 4 and USB4 Chromebook computers; and M series iPad Pro.

—Connect up to One 8K or Two 5K Monitors—
Depending on your computer’s video capability, the Echo 11 Thunderbolt 4 Dock supports one (always 4K or 5K; up to 6K or 8K) monitor through its Thunderbolt ports, or up to two 5K or Apple Pro Display XDR monitors; see Displays Compatibility PDF for full details on monitor and resolution support. You can plug in Thunderbolt 3 or USB-C monitors directly, or, you may connect other display types (HDMI, DisplayPort, etc.) by using a Thunderbolt compatible adapter (sold separately).

—Powerful 10Gbps USB ports—
The Echo 11 Thunderbolt 4 Dock features three USB 3.2 Gen 2 (10Gbps) Type A ports on the back to support super fast USB NVMe SSDs at up to full speed. And unlike some other docks, the Echo 11 doesn’t skimp on power either — each port provides up to 7.5W, ensuring bus-powered devices will operate without fail.

—Leave Your Charger In the Backpack—
Connected to your portable computer with the included Thunderbolt 4 cable, the Echo 11 Thunderbolt 4 Dock provides up to 90W of power (Power Delivery), meaning it can power and charge your computer while connected, even when not in use, allowing you to leave your computer’s power adapter packed away.

—Fast Wired Network Connection—
The Echo 11 Thunderbolt 4 Dock includes a Gigabit Ethernet port, perfect for connecting your broadband internet directly to your computer without another device competing for bandwidth on your WiFi setup. With the appropriate drivers already installed under macOS and Windows, setup is simple.

—Fast UHS-II SD 4.0 Card Reader—
The included SD card slot is compatible with SD, SDHC, and SDXC memory cards, and supports 300 MB/s read speeds with UHS-II SDXC cards to quickly offload images and video.

* See Sonnet website for details
