The Most Compact Thunderbolt 5 Hub

The CalDigit Element 5 Hub (E5) is a truly unique device. It features more ports than any other Thunderbolt hub. It does this while also maintaining the exact same compact size as the previous Thunderbolt 4 Element Hub. With a wide selection of powerful ports, it is an ideal solution for expanding workflows, while taking up minimal desk space.

Even though the device is compact, it includes features found in high-end docks, such as 90W of consistent host charging, up to 120Gb/s connectivity, and support for up to 3 displays on supported Windows Thunderbolt 5 PCs.

Interface

1 x Thunderbolt 5 Host (Up to 120Gb/s)
3 x Thunderbolt 5 (80Gb/s)
3 x USB-A (10Gb/s)
2 x USB-C (10Gb/s)
1 x DC In (20V | 9A)

Minimum System Requirements

macOS 15 or above
Windows 11 or above
iPadOS
Chrome OS
Thunderbolt 5 Computer
Thunderbolt 4 Computer
Thunderbolt 3 Mac
USB-C (USB4 or USB4 v2) Computer
USB-C Computer/Tablet/Phone
Thunderbolt/USB4 iPad
USB-C ChromeBook

Power Delivery

Up to 90W Host Charging
Each Downstream Thunderbolt 5 / USB4 v2 Port: 15W (5V/3A)
Each USB-A Port: 7.5W (5V/1.5A)
Each USB-C Port: 7.5W (5V/1.5A)

Size & Weight

Height: 1.0″ (25.5mm)
Width: 2.75″ (70 mm)
Length: 4.48″ (114mm)
Weight: 0.44lbs (0.20kg)
